The BOSE F1 Model 812 Flexible Array loudspeaker is the first powered portable loudspeaker that lets you control its vertical coverage pattern. Simply push or pull the array into position to create Straight, C, J or Reverse J coverage patterns. And once set, the system automatically changes the EQ to maintain optimum tonal balance for each coverage pattern. So, whether you'e playing at floor level, on a stage, or facing raked seats or bleachers, you can now adapt your PA to match the room.

Great for numerous applications:
Live music performances
Bands of all styles
Solo musicians
Mobile DJs
Houses of worship
Schools and universities
Resorts and hospitality venues
Business presentations

Features

  • Flex array is a flexible baffle that can be configured into four unique shapes (Straight, C, J or Reverse J), allowing the customer to choose the best possible coverage pattern for the application
  • Vertically oriented 8-driver mid/high line array, with each driver mounted on a custom 100 waveguide, helps deliver wide, consistent coverage
  • 12" LF driver provides high performance at low frequency for strong low-frequency output
  • Bi-amplified design with two high-output, Class-D amplifiers to separately power the FLEX array and 12" LF driver
  • Two input channels with independent volume controls and Line Level/Mic switch on Channel 1

    • Specs

    System Performance
    • System Type: Self powered, two-way
    • Frequency Response: (±3dB) 55Hz–14kHz
    • Frequency Range: (-10dB) 48Hz–16kHz
    • Nominal Dispersion: 100H x 40V (C-position)
    • Maximum SPL @ 1 m: 132dB SPL (peak)
    • Crossover Frequency: 600Hz Acoustic 4th order Butterworth
    Amplification
    • System Power: 1,000W
    • Distortion at Rated Power: 0.1 % Max (30Hz–15kHz)
    • System Limiter: Dynamic limiter
    • Power Indicator: Blue LED: system on
    Transducers
    • Driver Compliment: 8x2.25" mid-high drivers; 1x12" LF
    Channels
    • Signal Indicators: POWER/FAULT, LIMIT, FRONT LED, SIGNAL INPUT
    Input Connections
    • Channel 1: XLR Balanced: Pin 1 (GND), Pin 2 (+), Pin 3 (-)
    • Channel 2: 1/4" TS/TRS, 1ˆ, 8 TS/TRS, (2) RCA
    • Controls: Volume level, Signal input select, Front LED function select, EQ select, Power on/off
    Additional Connections
    • Line Output: XLR balanced
    • AC Mains: IEC Connector
    Physical
    • Enclosure: High-impact composite materials
    • Grille: Powder-coated perforated steel grille
    • Dimensions (HxWxD): 26.1" x 13.1" x 14.6", (664.66 x 334.3 x 372.5 mm)
    • Net Weight: 44.5 lb. (20.18 kg)
    Power Supply Voltages
    • Universal AC power rating: 100-240V 50/60Hz +/- 20 %, 200W max

Bose F1 Model 812 Flexible Array Speakers

  • Product Code: 1438614490018
The BOSE F1 Model 812 Flexible Array loudspeaker is the first powered portable loudspeaker that lets you control its vertical coverage pattern. Simply push or pull the array into position to create Straight, C, J or Reverse J coverage patterns. And once set, the system automatically changes the EQ to maintain optimum tonal balance for each coverage pattern. So, whether you'e playing at floor level, on a stage, or facing raked seats or bleachers, you can now adapt your PA to match the room.

Great for numerous applications:
Live music performances
Bands of all styles
Solo musicians
Mobile DJs
Houses of worship
Schools and universities
Resorts and hospitality venues
Business presentations

Features

  • Flex array is a flexible baffle that can be configured into four unique shapes (Straight, C, J or Reverse J), allowing the customer to choose the best possible coverage pattern for the application
  • Vertically oriented 8-driver mid/high line array, with each driver mounted on a custom 100 waveguide, helps deliver wide, consistent coverage
  • 12" LF driver provides high performance at low frequency for strong low-frequency output
  • Bi-amplified design with two high-output, Class-D amplifiers to separately power the FLEX array and 12" LF driver
  • Two input channels with independent volume controls and Line Level/Mic switch on Channel 1

    • Specs

    System Performance
    • System Type: Self powered, two-way
    • Frequency Response: (±3dB) 55Hz–14kHz
    • Frequency Range: (-10dB) 48Hz–16kHz
    • Nominal Dispersion: 100H x 40V (C-position)
    • Maximum SPL @ 1 m: 132dB SPL (peak)
    • Crossover Frequency: 600Hz Acoustic 4th order Butterworth
    Amplification
    • System Power: 1,000W
    • Distortion at Rated Power: 0.1 % Max (30Hz–15kHz)
    • System Limiter: Dynamic limiter
    • Power Indicator: Blue LED: system on
    Transducers
    • Driver Compliment: 8x2.25" mid-high drivers; 1x12" LF
    Channels
    • Signal Indicators: POWER/FAULT, LIMIT, FRONT LED, SIGNAL INPUT
    Input Connections
    • Channel 1: XLR Balanced: Pin 1 (GND), Pin 2 (+), Pin 3 (-)
    • Channel 2: 1/4" TS/TRS, 1ˆ, 8 TS/TRS, (2) RCA
    • Controls: Volume level, Signal input select, Front LED function select, EQ select, Power on/off
    Additional Connections
    • Line Output: XLR balanced
    • AC Mains: IEC Connector
    Physical
    • Enclosure: High-impact composite materials
    • Grille: Powder-coated perforated steel grille
    • Dimensions (HxWxD): 26.1" x 13.1" x 14.6", (664.66 x 334.3 x 372.5 mm)
    • Net Weight: 44.5 lb. (20.18 kg)
    Power Supply Voltages
    • Universal AC power rating: 100-240V 50/60Hz +/- 20 %, 200W max
  • Brand: Bose
  • Viewed: 18
  • Availability: In Stock
Bose

$1,343.00
