Bose F1 Model 812 flexible array loudspeaker pair for live sound and DJ performance

Bose F1 Model 812 Flexible Array Speakers

$1,343.00

Brand: Bose
Product Code: 1438614490018
Availability: In Stock

Description
Reviews (0)

Professional Sound Solution for Live Events and DJs

The BOSE F1 Model 812 Flexible Array loudspeaker is the first powered portable loudspeaker that lets you control its vertical coverage pattern. Simply push or pull the array into position to create Straight, C, J or Reverse J coverage patterns. And once set, the system automatically changes the EQ to maintain optimum tonal balance for each coverage pattern. So, whether you'e playing at floor level, on a stage, or facing raked seats or bleachers, you can now adapt your PA to match the room.

Great for numerous applications:
Live music performances
Bands of all styles
Solo musicians
Mobile DJs
Houses of worship
Schools and universities
Resorts and hospitality venues
Business presentations

Features

Flex array is a flexible baffle that can be configured into four unique shapes (Straight, C, J or Reverse J), allowing the customer to choose the best possible coverage pattern for the application
Vertically oriented 8-driver mid/high line array, with each driver mounted on a custom 100 waveguide, helps deliver wide, consistent coverage
12" LF driver provides high performance at low frequency for strong low-frequency output
Bi-amplified design with two high-output, Class-D amplifiers to separately power the FLEX array and 12" LF driver
Two input channels with independent volume controls and Line Level/Mic switch on Channel 1

Specs

System Performance

System Type: Self powered, two-way
Frequency Response: (±3dB) 55Hz–14kHz
Frequency Range: (-10dB) 48Hz–16kHz
Nominal Dispersion: 100H x 40V (C-position)
Maximum SPL @ 1 m: 132dB SPL (peak)
Crossover Frequency: 600Hz Acoustic 4th order Butterworth

Amplification

System Power: 1,000W
Distortion at Rated Power: 0.1 % Max (30Hz–15kHz)
System Limiter: Dynamic limiter
Power Indicator: Blue LED: system on

Transducers

Driver Compliment: 8x2.25" mid-high drivers; 1x12" LF

Channels

Signal Indicators: POWER/FAULT, LIMIT, FRONT LED, SIGNAL INPUT

Input Connections

Channel 1: XLR Balanced: Pin 1 (GND), Pin 2 (+), Pin 3 (-)
Channel 2: 1/4" TS/TRS, 1ˆ, 8 TS/TRS, (2) RCA
Controls: Volume level, Signal input select, Front LED function select, EQ select, Power on/off

Additional Connections
